SMC PSE301-LAC Pressure Sensor Controller

(No reviews yet) Write a Review
SKU:
PSE301-LAC
Condition:
New
Manufacturer Part #:
PSE301-LAC
SI Unit Specification:
Unit Change Function
SI Unit Output Polarity:
Unit Change Function
Body Option:
Power Source, Output Connection Cable
Body Option 2:
Bracket
Connector Type:
Standard Connector Type
  • SMC PSE301-LD controller, remote display, PSE200/300/530-560
  • <h2>PSE300, Pressure Sensor Monitor, 1 Screen, Switch and Analog Outputs</h2><p><h3>PSE300 is a pressure sensor monitor with a 3 + 1/2 digit, 2 color display. This monitor pairs with any PSE sensor, adding functionality similar to an ISE sensor with integrated display. Instantaneous readings are shown in red or green, or shifted from one to the other to alert reaching a target condition. Two available switch outputs are also indicated with LEDs. Other functions permit calibration, peak/bottom readings, error indications, key lock, and anti-chatter. PSE300 models are UL/CSA, CE and RoHS compliant, with an IP40 enclosure rating.<br>- </h3>- Permits viewing of PSE remote pressure sensor values in operator area<br>- Interprets voltage or current signal inputs<br>- 7 pressure units: MPa, kPa, kgf/cm2, bar, psi, inHg, mmHg<br>- 2 switch outputs (NPN or PNP) plus 1 analog output (V or mA)<br>- 2 snap-fit socket connections for power and sensor cables<br>- DIN rail/Terminal block, bracket or panel mounting options<br>- <p><a href="https://content2.smcetech.com/pdf/PSE.pdf" target="_blank">Series Catalog</a>
$97.20

Description

PSE300, Pressure Sensor Monitor, 1 Screen, Switch and Analog Outputs

PSE300 is a pressure sensor monitor with a 3 + 1/2 digit, 2 color display. This monitor pairs with any PSE sensor, adding functionality similar to an ISE sensor with integrated display. Instantaneous readings are shown in red or green, or shifted from one to the other to alert reaching a target condition. Two available switch outputs are also indicated with LEDs. Other functions permit calibration, peak/bottom readings, error indications, key lock, and anti-chatter. PSE300 models are UL/CSA, CE and RoHS compliant, with an IP40 enclosure rating.
-

- Permits viewing of PSE remote pressure sensor values in operator area
- Interprets voltage or current signal inputs
- 7 pressure units: MPa, kPa, kgf/cm2, bar, psi, inHg, mmHg
- 2 switch outputs (NPN or PNP) plus 1 analog output (V or mA)
- 2 snap-fit socket connections for power and sensor cables
- DIN rail/Terminal block, bracket or panel mounting options
-

Series Catalog

AutoCAD File
