WAGO 2000-1203

(No reviews yet) Write a Review
SKU:
2000-1203
Condition:
New
  • Wago 2000-1203
  • Wago 2000-1203
$1.52

Description

TOPJOBS feedthrough terminal block; rail mount; 2-conductor; 3.5 mm wide; red
View AllClose

Additional Information

actuation type:
Push-in || Operating tool
approvals per:
UL 1059
color:
Red
connectable conductor materials:
Copper
connection technology:
Push-in CAGE CLAMP
country of origin sales organisation germany:
CN
depth from upper edge of din rail:
32.9 mm / 1.295 inch
design:
Horizontal type
fine stranded conductor:
0.14 1.5 mm / 24 16 AWG
fine stranded conductor with ferrule push in termination:
0.5 0.75 mm / 20 18 AWG
fine stranded conductor with insulated ferrule:
0.14 0.75 mm / 24 18 AWG
fire load:
0.079 MJ
flammability class per ul94:
V0
height:
48.5 mm / 1.909 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 3) Overvoltage category III / Pollution degree 3
marking level:
Center/side marking
mounting type:
DIN-35 rail
nominal cross section:
1 mm
nominal voltage iii 3:
800 V
note conductor cross section:
Depending on the conductor characteristic, a conductor with a smaller cross-section can also be inserted via push-in termination.
packaging type:
Box
rated current:
13.5 A
rated current 2:
17.5 A
rated current csa use group b:
0.416666666666667
rated current csa use group c:
0.416666666666667
rated current ex e ii:
13 A
rated current ex e ii with jumper:
0
rated current ul use group b:
15 A
rated current ul use group c:
15 A
rated surge voltage iii 3:
8 kV
rated voltage csa use group b:
600 V
rated voltage csa use group c:
600 V
rated voltage en ex e ii:
550 V
rated voltage ul use group b:
600 V
rated voltage ul use group c:
600 V
ratings per:
ATEX: PTB 11 ATEX 1041 U / IECEx: PTB 11.0093U (Ex eb IIC Gb)
solid conductor:
0.14 1.5 mm / 24 16 AWG
solid conductor push in termination:
0.5 1.5 mm / 20 16 AWG
strip length:
9 11 mm / 0.35 0.43 inch
weight:
3.580 g
width:
3.5 mm / 0.138 inch
wiring direction:
Front-entry wiring
