WAGO 231-316/037-000

(No reviews yet) Write a Review
SKU:
231-316/037-000
Condition:
New
  • Wago 231-316/037-000
  • Wago 231-316/037-000
  • Wago 231-316/037-000
$15.62

Description

1-conductor female connector; CAGE CLAMP; 2.5 mm²; Pin spacing 5.08 mm; 16-pole; Lateral locking levers; 2,50 mm²; orange
View AllClose

Additional Information

actuation type:
Operating tool
approvals per:
UL 1059
clamping spring material:
Chrome nickel spring steel (CrNi)
color:
Orange
conductor entry direction to mating direction:
0
connection technology:
CAGE CLAMP
connector connection type:
For conductor
contact material:
Copper alloy
contact plating:
Tin-plated
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
DE
depth:
29.6 mm / 1.165 inch
fine stranded conductor:
0.08 2.5 mm / 28 12 AWG
fine stranded conductor with insulated ferrule:
0.25 1.5 mm
fine stranded conductor with uninsulated ferrule:
0.25 2.5 mm
fire load:
0.451 MJ
flammability class per ul94:
V0
height:
14.3 mm / 0.563 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +85 C
locking of plug in connection:
Locking lever
material group:
I
mismating protection:
No
nominal voltage ii 2:
630 V
nominal voltage iii 3:
320 V
packaging type:
Box
pin spacing:
5.08 mm / 0.2 inch
pole no:
16
rated current:
16 A
rated current csa use group b:
15 A
rated current csa use group d:
0.416666666666667
rated current ul 1977:
15 A
rated current ul use group b:
15 A
rated current ul use group d:
0.416666666666667
rated surge voltage ii 2:
4 kV
rated surge voltage iii 2:
4 kV
rated surge voltage iii 3:
4 kV
rated voltage csa use group b:
300 V
rated voltage csa use group d:
300 V
rated voltage iii 2:
320 V
rated voltage ul 1977:
600 V
rated voltage ul use group b:
300 V
rated voltage ul use group d:
300 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
solid conductor:
0.08 2.5 mm / 28 12 AWG
strip length:
8 9 mm / 0.31 0.35 inch
weight:
30.550 g
width:
97.88 mm / 3.854 inch
