WAGO 232-137

(No reviews yet) Write a Review
SKU:
232-137
Condition:
New
  • Wago 232-137
  • Wago 232-137
  • Wago 232-137
  • Wago 232-137
  • Wago 232-137
$5.02

Description

THT female header; straight; Pin spacing 5 mm; 7-pole; 0.6 x 1.0 mm solder pin; gray
View AllClose

Additional Information

approvals per:
UL 1059
color:
Gray
connector connection type:
For PCB
contact material:
Copper alloy
contact plating:
Tin-plated
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
DE
depth:
11.6 mm / 0.457 inch
drilled hole diameter with tolerance:
1.3 (+0.1) mm
fire load:
0.115 MJ
flammability class per ul94:
V0
height:
23.25 mm / 0.915 inch
height from the surface:
18.25 mm / 0.719 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +85 C
locking of plug in connection:
Without
material group:
I
mating direction to the pcb:
90
mismating protection:
No
nominal voltage ii 2:
630 V
nominal voltage iii 3:
320 V
number of solder pins per potential:
1
packaging type:
Box
pcb contact:
THT
pin spacing:
5 mm / 0.197 inch
pole no:
7
rated current:
0
rated current csa use group b:
15 A
rated current csa use group d:
0.416666666666667
rated current ul 1977:
15 A
rated current ul use group b:
15 A
rated current ul use group d:
0.416666666666667
rated surge voltage ii 2:
4 kV
rated surge voltage iii 2:
4 kV
rated surge voltage iii 3:
4 kV
rated voltage csa use group b:
300 V
rated voltage csa use group d:
300 V
rated voltage iii 2:
320 V
rated voltage ul 1977:
600 V
rated voltage ul use group b:
300 V
rated voltage ul use group d:
300 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
solder pin arrangement:
Over the entire female connector (in-line)
solder pin dimensions:
0.6 x 1 mm
solder pin length:
5 mm
weight:
6.522 g
width:
36.5 mm / 1.437 inch
