WAGO 721-303/031-000

(No reviews yet) Write a Review
SKU:
721-303/031-000
Condition:
New
$3.67

Description

1-conductor female connector, angled; CAGE CLAMP; 2.5 mm²; Pin spacing 5 mm; 3-pole; 100% protected against mismating; clamping collar; 2,50 mm²; light gray
View AllClose

Additional Information

actuation type:
Operating tool
approvals per:
CSA
clamping spring material:
Chrome nickel spring steel (CrNi)
color:
Light gray
conductor entry direction to mating direction:
90
connection technology:
CAGE CLAMP
connector connection type:
For conductor
contact material:
Copper alloy
contact plating:
Tin-plated
contact type pluggable connector:
Female connector/socket
country of origin sales organisation germany:
PL
depth:
27.25 mm / 1.073 inch
design:
Angled: mountable
fine stranded conductor:
0.08 2.5 mm / 28 12 AWG
fine stranded conductor with insulated ferrule:
0.25 1.5 mm
fine stranded conductor with uninsulated ferrule:
0.25 2.5 mm
fire load:
0.130 MJ
flammability class per ul94:
V0
height:
13.1 mm / 0.516 inch
housing sheet thickness:
0.6 1.2 mm / 0.024 0.047 inch
insulation material:
Polyamide (PA66)
legend ratings:
(III / 2) Overvoltage category III / Pollution degree 2
limit temperature range:
-60 +85 C
locking of plug in connection:
Without
material group:
I
mismating protection:
Yes
mounting type:
Mounting flange || Panel mounting
nominal voltage ii 2:
630 V
nominal voltage iii 3:
320 V
packaging type:
Box
pin spacing:
5 mm / 0.197 inch
pole no:
3
rated current:
0
rated current csa use group b:
15 A
rated current csa use group d:
0.416666666666667
rated current ul 1977:
15 A
rated current ul use group b:
15 A
rated current ul use group d:
0.416666666666667
rated surge voltage ii 2:
4 kV
rated surge voltage iii 2:
4 kV
rated surge voltage iii 3:
4 kV
rated voltage csa use group b:
300 V
rated voltage csa use group d:
300 V
rated voltage iii 2:
320 V
rated voltage ul 1977:
600 V
rated voltage ul use group b:
300 V
rated voltage ul use group d:
300 V
ratings per:
IEC/EN 60664-1
safety information 1:
The MCS MULTI CONNECTION SYSTEM includes connectors without breaking capacity in accordance with DIN EN 61984. When used as intended, these connectors must not be connected/disconnected when live or under load. The circuit design should ensure
solid conductor:
0.08 2.5 mm / 28 12 AWG
strip length:
7 8 mm / 0.28 0.31 inch
weight:
5.348 g
width:
22.8 mm / 0.898 inch
