ABB AF12ZB-30-10RT-23 AF12ZB 3-Pole Railway Contactor, 1NO Auxiliary, 100-250V AC/DC Coil
ABB
$151.11
ABB AF12ZB-30-10RT-23 3-Pole Railway Contactor, 100-250V AC/DC Coil
The ABB AF12ZB-30-10RT-23 is a 3-pole railway contactor from the ABB AF12 range with 1NO auxiliary contacts and a 100-250 V AC/DC (50/60 Hz) coil. It is designed to switch power circuits up to 690 V AC / 220 V DC. Its electronic coil interface accepts a wide control voltage range, so one coil covers multiple supply voltages, and built-in surge suppression removes the need for add-on suppressors.
It is typically used for railway rolling stock, including installation in passenger and driver cabins. Automation Distribution supplies the AF12ZB-30-10RT-23 as an authorized ABB distributor.
Key Features
- 3-Pole main contacts
- 1NO auxiliary contacts
- Coil voltage: 100-250 V AC/DC (50/60 Hz)
- Switches power circuits up to 690 V AC / 220 V DC
- Ring-Tongue Terminals
Specifications
| Manufacturer | ABB |
| Part Number | AF12ZB-30-10RT-23 |
| Series | AF12 |
| Product Type | Railway Contactor |
| Number of Poles | 3 |
| Auxiliary Contacts | 1NO |
| Coil Voltage | 100-250 V AC/DC (50/60 Hz) |
| Maximum Operational Voltage | 690 V AC / 220 V DC |
| Terminal Type | Ring-Tongue Terminals |
Part Number Breakdown: AF12ZB-30-10RT-23
| Code | Meaning |
|---|---|
| AF12ZB | Railway Contactor frame AF12ZB |
| 30 | Main poles: 3-Pole |
| 10 | Auxiliary contacts: 1NO |
| RT | Variant suffix (see ABB datasheet) |
| 23 | Coil code: 100-250 V AC/DC (50/60 Hz) |
Authorized ABB Distributor. Automation Distribution supplies genuine ABB motor control products. Contact our team for technical support, cross-references or volume pricing on the AF12ZB-30-10RT-23.
