ABB CR101BE1C Reversing Manual Motor Switch, 3-Pole, NEMA 1, Up-Stop-Down, 2 HP at 240V AC
ABB
$356.00
The ABB CR101BE1C (catalog 101BE1C, ABB part 7GSP007869R0006) is a 3-pole reversing manual motor-starting switch with a three-position up-stop-down toggle operator, housed in a NEMA Type 1 enclosure and rated 2 HP at 240V AC. It is built for self-protected single-phase and three-phase motors in ON/OFF and forward/reverse applications where separate overload protection is not required. As part of the long-running CR101 line (originally a General Electric / GE Industrial Solutions product, now manufactured under the ABB brand), it remains a dependable, economical choice for simple manual motor control.
Specifications at a Glance
| Catalog Number | CR101BE1C / 101BE1C |
| ABB Part Number | 7GSP007869R0006 |
| Product Type | Manual motor-starting switch (reversing) |
| Poles | 3-pole |
| Operator | Up-Stop-Down toggle (forward / off / reverse) |
| Horsepower / Voltage | Up to 2 HP at 240V AC |
| Motor Compatibility | Self-protected single-phase & three-phase |
| Enclosure | NEMA Type 1 |
| Overload Protection | None (switch only - for self-protected motors) |
| Series | ABB CR101 (legacy GE Industrial Solutions) |
| Brand | ABB |
What the CR101BE1C Does
The CR101BE1C provides simple, reliable manual control for reversing-duty motors. Its defining feature is the up-stop-down operator: a single three-position toggle that selects one motor direction in the up position, a center off (stop) position, and the opposite direction in the down position. Because all three poles switch together, the device handles three-phase motor reversing as well as single-phase ON/OFF switching, all from one panel-mountable manual control.
This is a switching device, not an overload starter. It is intended for motors that are already self-protected (for example, motors with built-in thermal protectors) or for circuits where overload protection is provided elsewhere. That makes the CR101BE1C an economical answer when an application needs straightforward manual on/off and direction control without the cost and bulk of a full overload starter.
Typical Applications
Common uses for a 3-pole reversing manual motor switch with an up-stop-down operator include:
- Manual forward/reverse control of small self-protected three-phase motors
- Material-handling equipment, small hoists, gates, and damper drives
- Conveyors and machine sub-assemblies needing operator-selected direction
- OEM machinery and replacement of legacy GE CR101 reversing switches
- Fractional and small integral-horsepower motor circuits up to 2 HP at 240V AC
Need overload and short-circuit protection? The CR101BE1C is a switch only. If your motor is not self-protected and you require integrated overload plus short-circuit protection, look at ABB's MS-series manual motor protectors, such as the ABB MS116-16, MS132-1.6, and MS450-45, which combine manual switching with trip-rated motor protection.
GE / General Electric cross-reference: The CR101 line originated with General Electric (GE Industrial Solutions) and is now produced under the ABB brand. If you are sourcing a GE CR101BE1C or GE 101BE1C, this ABB-branded part is the current production equivalent.
Related CR101 Manual Motor Controls
- ABB CR101H Fractional HP Manual Motor Starter
- ABB CR101H1 Fractional HP Manual Motor Starter
- ABB CR101Y1 Fractional HP Manual Motor Starter
Frequently Asked Questions
Does the ABB CR101BE1C have overload protection?
No. The CR101BE1C is a manual motor-starting switch, not an overload starter. It is designed for self-protected motors or circuits where overload protection is supplied separately. For built-in overload and short-circuit protection, use an ABB MS-series manual motor protector instead.
What does the up-stop-down operator do?
It is a three-position maintained toggle. The up and down positions run the motor in opposite directions (forward and reverse), and the center stop position turns the motor off. This is what makes the CR101BE1C a reversing switch rather than a simple on/off device.
Is the CR101BE1C a GE or an ABB part?
Both names refer to the same product. The CR101 series was originally a General Electric (GE Industrial Solutions) line and is now manufactured under the ABB brand. GE CR101BE1C and ABB CR101BE1C are the same device.
What motors can it control?
Self-protected single-phase and three-phase motors up to 2 HP at 240V AC. Because it is 3-pole and reversing, it suits small three-phase motors that need manual direction control.
What enclosure does it come in?
The CR101BE1C is supplied in a NEMA Type 1 enclosure for general-purpose indoor mounting.
