Description
Overview
ABB
Illuminated Pushbuttons, MODULAR Series
Item# MP1-62L20F8 - PB MOM FLSH ILL BLU
MODULAR Series Information
- 22mm or 30mm Mounting Size
- Incandescent or LED Types
- Finger-Safe Screw Terminals
- NEMA 13,4X; IP66
- UL; CSA; IEC Approvals
- Can Be Used in Tough Environments
- Up to Six Contact Blocks on One Actuator
- Easy to Mount and Wire
Specifications
Item Number:
MP1-62L20F8
UPC:
804325374835
Brand:
ABB
Item Category:
Switches
Subcategory:
Pushbutton Illuminated
Series:
MODULAR
Nominal Mounting Size:
22 MilliMeters
Operation:
Momentary
Contacts:
2NO
Lens/Button Shape:
Round Flush
Lens/Button Color:
Blue
Lamp Type:
Incandescent
Nominal Lamp Voltage:
24 VAC;24 VDC
Illumination Circuit:
Full Voltage
Terminal Type:
Fingersafe Screw
Bezel:
Metal Round
Full Shroud:
No
Max Voltage:
600 VAC;600 VDC
Current (A):
10 Amps
IEC Rating:
IP66
NEMA Rating:
13;4X
Depth Behind Panel:
1.91 Inches
Approvals:
UL;CSA;IEC
H x W x D:
16 in x 1.69 in x 1.18 in
Net Weight:
2.42 OZ
Gross Weight:
2.42 OZ
