ABB NF44EK-12 Contactor Relay, 4NO+4NC, 48-130V AC/DC Coil
The ABB NF44EK-12 is a contactor relay from the ABB NF..K range with 4NO+4NC contacts and a 48-130 V AC/DC (50/60 Hz) coil. Its electronic coil interface accepts a wide control voltage range and has built-in surge suppression. The contacts are mechanically linked per IEC 60947-5-1 Annex L, which supports safe feedback in control circuits.
It is typically used for switching auxiliary and control circuits in machine and panel control. Automation Distribution supplies the NF44EK-12 as an authorized ABB distributor.
Key Features
- 4NO+4NC contacts
- Coil voltage: 48-130 V AC/DC (50/60 Hz)
- Built-in surge suppression
- Push-in Spring Terminals
Specifications
| Manufacturer | ABB |
| Part Number | NF44EK-12 |
| Series | NF..K |
| Product Type | Contactor Relay |
| Contacts | 4NO+4NC |
| Number of Poles | 8 |
| Coil Voltage | 48-130 V AC/DC (50/60 Hz) |
| Terminal Type | Push-in Spring Terminals |
Part Number Breakdown: NF44EK-12
| Code | Meaning |
|---|---|
| NF | NF contactor relay |
| 44 | Contacts: 4NO+4NC |
| EK | Electronic coil interface, K variant (see ABB datasheet) |
| 12 | Coil code: 48-130 V AC/DC (50/60 Hz) |
Authorized ABB Distributor. Automation Distribution supplies genuine ABB control relays. Contact our team for technical support, cross-references or volume pricing on the NF44EK-12.
- Series:
- NF..K
- Contacts:
- 4NO+4NC
- Number of Poles:
- 8
- Coil Voltage:
- 48-130 V AC/DC (50/60 Hz)
- Terminal Type:
- Push-in Spring Terminals
- Spec Sheet:
- View
