ABB SU201ML-K20 SU200ML Miniature Circuit Breaker, 1-Pole, 20A, K Curve, UL 489
ABB
$48.98
ABB SU201ML-K20 SU200ML Miniature Circuit Breaker, 1-Pole, 20 A, K Curve
The ABB SU201ML-K20 is a 1-pole miniature circuit breaker from the ABB SU200ML series, rated 20 A with a K tripping characteristic. It is UL 489 listed, so it can be used for branch circuit protection in control panels, machinery and building distribution.
The K curve trips instantaneously at 8 to 14 x In, which makes it a strong fit for motors, transformers and other inductive loads with high inrush current. Automation Distribution supplies the SU201ML-K20 as an authorized ABB distributor.
Key Features
- 1-pole construction, rated current 20 A
- K tripping characteristic, magnetic trip at 8 to 14 x In
- Thermal trip for overload protection and electromagnetic trip for short-circuit protection
- 35 mm DIN rail mounting
- UL 489 listed for branch circuit protection
Specifications
| Manufacturer | ABB |
| Part Number | SU201ML-K20 |
| Series | SU200ML |
| Product Type | Miniature Circuit Breaker |
| Number of Poles | 1 |
| Rated Current | 20 A |
| Tripping Characteristic | K curve (8 to 14 x In) |
| UL Standard | UL 489 (branch circuit protection) |
| Mounting | 35 mm DIN rail |
Part Number Breakdown: SU201ML-K20
| Code | Meaning |
|---|---|
| SU201ML | SU200ML series, 1-pole |
| K | Tripping characteristic: K curve |
| 20 | Rated current: 20 A |
Typical Applications
The SU201ML-K20 is typically selected for motors, transformers and other inductive loads with high inrush current, with UL 489 branch circuit protection for industrial control panels and OEM machinery.
Authorized ABB Distributor. Automation Distribution supplies genuine ABB circuit protection products. Contact our team for technical support, cross-references or volume pricing on the SU201ML-K20.
- Series:
- SU200ML
- Number of Poles:
- 1
- Rated Current:
- 20 A
- Tripping Characteristic:
- K curve (8 to 14 x In)
- UL Standard:
- UL 489 (branch circuit protection)
- Mounting:
- 35 mm DIN rail
