ABB TEY325 MCCB 3P 25A Bolt-On Circuit Breaker for Grounded 480Y/277 Vac Systems - Compact Design with Quick-Make/Quick-Break Mechanisms and Customizable Accessories

ABB TEY325 MCCB 3P 25A Bolt-On Circuit Breaker for Grounded 480Y/277 Vac Systems - Compact Design with Quick-Make/Quick-Break Mechanisms and Customizable Accessories

ABB
SKU:
TEY325
|
UPC:
783164403480
Availability:
Commonly Stocked at Factory
$569.00
Condition:
New
Current Stock:
Description
The ABB TEY325 MCCB 3P 25A Bolt-On circuit breaker is designed for optimal performance and safety in grounded 480Y/277 Vac systems. Its compact design, with a one-inch width per pole, allows for efficient use of space while providing robust protection. The bolt-on mounting base accessory enhances its versatility, making it ideal for various applications as a lug-lug breaker. This circuit breaker features Quick-make / Quick-break mechanisms, common trip bars, and a clear trip indication for easy monitoring and reliability. Available in 1, 2, and 3 pole versions, the TEY series can be customized with auxiliary contact and shunt trip accessories to meet specific needs.
Additional Information
Trip Range:
Non-Interchangeable
Connection:
14-8 kcmil / 12-8 kcmil
Application:
Thermal Magnetic
Number Of Poles:
3
Trip Type:
LI
Frame:
TEY
Amperage Rating:
25A
Standard:
E11592
Load Rating:
HACR / HID
Sub Brand:
TEY
Brand Name:
TEY / Q-Line (Bolt-On)
Interrupt Rating:
14kA@277 Vac / 65kA@120 Vac / 65kA@120/240 Vac / 65kA@240 Vac
Spec Sheet:
View
