ABB THQC32090WL Circuit Breaker, 3-Pole, 90A, 240V, 10Ka - Compact Design for Residential and Commercial Use
ABB
$776.31
The ABB THQC32090WL Circuit Breaker is a robust and reliable solution for both residential and commercial electrical systems. This 3-pole, 90A, 240V circuit breaker is designed with a compact, one-inch wide per pole structure, making it ideal for space-constrained installations. Featuring a thermal-magnetic mechanism, it ensures efficient protection against overloads and short circuits. The Quick-make / Quick-break mechanism provides rapid response, while the common trip bars and easy-to-spot trip indication enhance safety and operational reliability. Designed for 35mm DIN rail mounting, this lug-lug version of the Q Line circuit breaker is versatile and adaptable. Additionally, it offers the option to include auxiliary contact and shunt trip accessories, catering to a wide range of electrical needs. With a 10Ka interrupting capacity, the ABB THQC32090WL Circuit Breaker is engineered to deliver superior performance and peace of mind.
- Load Rating:
- HACR
- Interrupt Rating:
- 10kA@120 Vac / 10kA@120/240 Vac / 10kA@240 Vac
- Number Of Poles:
- 3
- Amperage Rating:
- 90A
- Trip Type:
- LI
- Sub Brand:
- Q Line
- Frame:
- Q-Line
- Standard:
- E11592
- Brand Name:
- Q-Line (Lug-Lug)
- Application:
- Thermal Magnetic
- Trip Range:
- Non-Interchangeable
- Spec Sheet:
- View
