ABB XT5SQ340AEFF000XXX Molded Case Circuit Breaker

ABB XT5SQ340AEFF000XXX Tmax XT5S 400A Frame Molded Case Circuit Breaker, 3-Pole, 400A, Ekip Dip LS/I, 100% Rated, UL/CSA, UL/CSA

ABB
SKU:
XT5SQ340AEFF000XXX
|
UPC:
8057558507033
Availability:
60 Work Days
$3,641.74
Condition:
New
Current Stock:
Description

ABB XT5SQ340AEFF000XXX Tmax XT5S Molded Case Circuit Breaker, 3-Pole, 400 A

The ABB XT5SQ340AEFF000XXX is a 3-pole molded case circuit breaker from the ABB Tmax XT family, built on the XT5 frame with a 400 A frame rating and breaking capacity version S. It is fitted with an Ekip Dip electronic trip unit with long-time protection plus selectable short-time or instantaneous protection (LS/I), rated 400 A. This is the UL/CSA version and is 100% rated.

It is typically used for feeder protection that needs adjustable electronic trip settings and selectivity. Automation Distribution supplies the XT5SQ340AEFF000XXX as an authorized ABB distributor.

Key Features

  • Tmax XT5 frame, 400 A frame rating
  • Breaking capacity version S (see the ABB datasheet for interrupting ratings by voltage)
  • Ekip Dip electronic trip unit with long-time protection plus selectable short-time or instantaneous protection (LS/I), In = 400 A
  • 3-pole
  • Fixed version with front terminals
  • UL/CSA version, 100% rated

Specifications

ManufacturerABB
Part NumberXT5SQ340AEFF000XXX
SeriesTmax XT
FrameXT5
Frame Rating400 A
Breaking Capacity VersionS
Product TypeMolded Case Circuit Breaker
Number of Poles3
Trip UnitEkip Dip LS/I
Rated Current (In)400 A
VersionFixed, front terminals
CertificationUL/CSA
100% RatedYes

Part Number Breakdown: XT5SQ340AEFF000XXX

CodeMeaning
XT5Tmax XT5 frame
SBreaking capacity version S
QUL/CSA, 100% rated
33 poles
40ARated current code (400 A)
EEkip Dip electronic
FF000XXXTerminals, version and options (see ABB datasheet)

Authorized ABB Distributor. Automation Distribution supplies genuine ABB circuit protection products. Contact our team for technical support, cross-references or volume pricing on the XT5SQ340AEFF000XXX.

Additional Information
Series:
Tmax XT
Frame:
XT5
Frame Rating:
400 A
Breaking Capacity Version:
S
Number of Poles:
3
Trip Unit:
Ekip Dip LS/I
Rated Current (In):
400 A
Version:
Fixed, front terminals
Certification:
UL/CSA
100% Rated:
Yes
