Baumer IFBR 11N37T1/L-9 11014611
Baumer
$207.70
The Baumer IFBR 11N37T1/L-9 11014611 is a flush-mounted, hygienic design proximity sensor with a nominal sensing distance of 4 mm and adjustable hysteresis between 2 to 15% of Sr. It features a red LED output indicator and is equipped with multiple certifications including Ecolab, EHEDG, and various FDA and EC regulations, making it suitable for food and pharmaceutical applications. The sensor operates at a switching frequency of 1 kHz and has a voltage supply range of 6 to 30 VDC. It includes a NPN break function (NC) output circuit with a maximum output current of 200 mA and reduced current under cleaning temperatures. The sensor offers short circuit and reverse polarity protection, and is constructed with a stainless steel 1.4404 (V4A) housing and LCP sensing face. It has a cylindrical smooth design, measures 11 mm in diameter, 54 mm in length, and includes a 2-meter PVC cable for connection. The operating temperature ranges from -40 to +80 °C, with a higher tolerance during cleaning processes (80 to +100 °C for 30 min/day). It is highly durable with IP 68/69K and proTect+ ratings for protection against harsh environmental conditions.
- Mounting type:
- Flush
- Special type:
- Hygienic design
- Nominal sensing distance Sn:
- 4 mm
- Hysteresis:
- 2 15 % of Sr
- Output indicator:
- LED red
- Approvals/certificates:
- Ecolab Adapted from EHEDG REGULATION (EC) 1935/2004 REGULATION (EC) 2023/2006 REGULATION (EU) 1282/2011 FDA 21 CFR § 175.300 FDA 21 CFR § 177.2600 FCN 742
- Switching frequency:
- 1 kHz
- Voltage supply range +Vs:
- 6 30 VDC
- Current consumption max. (no load):
- 10 mA
- Output circuit:
- NPN break function (NC)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Output current (at cleaning temperature):
- < 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical smooth
- Material (sensing face):
- LCP
- Housing material:
- Stainless steel 1.4404 (V4A)
- Dimension:
- 11 mm
- Housing length:
- 54 mm
- Connection types:
- Cable PVC, 2 m
- Operating temperature:
- -40 +80 °C
- Cleaning temperature:
- 80 +100 °C (30 min/day)
- Protection class:
- IP 68/69K & proTect+
- Datasheet:
- View
