Baumer IFRM 18P17M1/PL 11013677
Baumer
$188.80
The Baumer IFRM 18P17M1/PL 11013677 is a flush-mounted, cylindrical threaded proximity sensor designed for outdoor use, featuring a nominal sensing distance of 10 mm and a hysteresis of 2 to 15% of Sr. It includes a red LED output indicator and operates at a switching frequency of 400 Hz. The sensor supports a voltage supply range of 6 to 36 VDC and has a maximum no-load current consumption of 24 mA. It utilizes a PNP make function (NO) output circuit with a voltage drop of less than 2 VDC and an output current of 200 mA. Equipped with short circuit and reverse polarity protection, the sensor is constructed with a PBT sensing face and a brass nickel-plated housing. It has a dimension of 18 mm in diameter and a housing length of 50 mm, connected via a 2-meter PUR cable. The sensor can withstand a tightening torque of up to 40 Nm and operates within a temperature range of -40 to +80 °C. It is rated at protection class IP 67, ensuring high durability and resistance to environmental conditions.
- Mounting type:
- Flush
- Special type:
- Outdoor design
- Nominal sensing distance Sn:
- 10 mm
- Hysteresis:
- 2 15 % of Sr
- Output indicator:
- LED red
- Switching frequency:
- 400 Hz
- Voltage supply range +Vs:
- 6 36 VDC
- Current consumption max. (no load):
- 24 mA
- Output circuit:
- PNP make function (NO)
- Voltage drop Vd:
- <2 VDC
- Output current:
- 200 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Design:
- Cylindrical threaded
- Material (sensing face):
- PBT
- Housing material:
- Brass nickel plated
- Dimension:
- 18 mm
- Housing length:
- 50 mm
- Connection types:
- Cable PUR 3 x 0,25, 2 m
- Tightening torque max.:
- 40 Nm (Front: 28 Nm)
- Operating temperature:
- -40 +80 °C
- Protection class:
- IP 67
- Datasheet:
- View
