Description

Baumer NE211.023AX02 Electronic Preset Counter

The Baumer NE211.023AX02 is a 5-digit LED electronic preset counter with two presets, used in cutting, positioning, and packaging applications where the machine must trigger an output action at predetermined counts. The counter accepts inputs from incremental encoders or digital sensors and offers programmable operating mode, start count, and scaling factor. Plug-in screw terminals simplify field replacement, and the panel-mount housing fits standard 48 48 mm cutouts. Find related models in our Baumer counters catalog.

Key Specifications

Manufacturer Part Number NE211.023AX02
Baumer Article Number 11033513
Counter Type Electronic preset counter
Series NE211
Display 5-digit LED
Number of Presets 2
Connection Type Plug-in screw terminals
Programmable Operating Mode Yes
Programmable Start Count Yes
Programmable Scaling Factor Yes
Compatible Inputs Incremental encoders, digital sensors
Mounting Panel mount

Typical Applications

  • Length cut-off control on cut-to-length machines and roll fed lines
  • Batch counting on packaging and bottling equipment
  • Position control on indexing tables and pick-and-place stations
  • Quantity preset for filling, stacking, and palletizing operations
  • Cycle limit enforcement on press and stamping equipment

Order the NE211.023AX02 from Automation Distribution, your authorized Baumer distributor.

Need application support or want to confirm fit for your build? Call 1-888-600-3080 or browse our full Baumer counter catalog.

Frequently Asked Questions

What is a preset counter, and how is it different from a totalizer?

A preset counter compares the running count against one or more user-set target values and triggers an output when those targets are reached used to drive cutoff knives, divert gates, or stop signals at predetermined quantities. A totalizer simply accumulates the count for display or logging without triggering output actions.

How many presets does the NE211.023AX02 support?

Two presets. Each can be assigned independently to a relay output, allowing two-stage actions like "slow-down at preset 1, stop at preset 2."

What input signals does the NE211 accept?

It is compatible with incremental encoder pulse inputs and digital sensor signals (typical industrial 24 VDC sourcing or sinking sensors). The scaling factor lets you convert raw pulses into engineering units like millimeters, meters, or part counts.

Can the NE211.023AX02 be reset remotely?

Yes. The plug-in terminal block provides a remote reset input alongside the count and direction inputs, so the counter can be zeroed by a PLC output or external pushbutton.
