Baumer O200.ER-NV1Z.72CV/H006 11210575 is a through beam sensor receiver designed for precise object detection with an actual range of 5 m and a nominal range of 6 m. It can recognize objects as small as 5 mm, and even 0.5 mm with an aperture. Features include a flashing output indicator for alignment or soiled lens, yellow LED output indicator, and green LED for power on indication. It does not have sensitivity adjustment but includes suppression of reciprocal influence. The response time is less than 0.5 ms. It operates on a voltage supply range of 10 to 30 VDC, with a typical current consumption of 16 mA at 24 VDC. The output function can be set to light or dark operate, and it includes NPN complementary output circuit with a maximum output current of 50 mA. It offers short circuit and reverse polarity protection. The sensor has a compact rectangular design, measuring 8 mm in width, 25.1 mm in height, and 14.1 mm in depth, with threaded sleeves M3 for mechanical mounting and a durable plastic housing made of ASA and PMMA. The connection is facilitated by a 4-pin, 2 m PVC cable. It operates within a temperature range of -25 to +50 °C and is rated IP 67 for protection against dust and water ingress.
- Type:
- Through beam sensor
- Emitter / receiver:
- Receiver
- Actual range Sb:
- 5 m
- Nominal range Sn:
- 6 m
- Smallest object recognizable typ.:
- 5 mm (0,5 mm with aperture)
- Alignment / soiled lens indicator:
- Flashing output indicator
- Output indicator:
- LED yellow
- Power on indication:
- LED green
- Sensitivity adjustment:
- No
- Suppression of reciprocal influence:
- Yes
- Response time / release time:
- < 0.5 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 20 mA (@ 30 VDC)
- Current consumption typ.:
- 16 mA (@ 24 VDC)
- Voltage drop Vd:
- <2 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 50 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 8 mm
- Height / length:
- 25.1 mm
- Depth:
- 14.1 mm
- Design:
- Rectangular
- Mechanical mounting:
- Threaded sleeves M3 (stainless steel)
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Cable characteristics:
- PVC / PVC 4 x 0.08 mm²
- Operating temperature:
- -25 +50 °C
- Protection class:
- IP 67
