Baumer O300.GR-NV1T.72CU/T003 11135882
Baumer
$210.90
The Baumer O300.GR-NV1T.72CU/T003 11135882 is a background suppression sensor with a sensing distance of 30 to 300 mm and a sensing range of 15 to 300 mm. It features a pulsed red LED light source with a wavelength of 630 nm and a quick response time of less than 1 ms. The sensor is equipped with LED indicators for power (green) and operation status (yellow), and offers qTeach and 1-Step Teach-in for easy distance adjustment. It supports a voltage supply range of 10 to 30 VDC, consumes a maximum of 45 mA with no load, and has a typical consumption of 30 mA. The output function can operate in light or dark conditions, and the sensor includes NPN complementary output circuit with a maximum output current of 100 mA. It also features short circuit and reverse polarity protection. The compact, rectangular design measures 12.9 mm in width, 32.3 mm in height, and 23 mm in depth, with a housing made of plastic (ASA, PMMA) and a PMMA front optics. The sensor is IP67 rated for protection against dust and water, and operates within a temperature range of -25 to +60 °C. It connects via a 4-pin, 2-meter cable.
- Type:
- Background suppression
- Sensing distance Tw:
- 30 300 mm
- Sensing range Tb:
- 15 300 mm
- Power on indication:
- LED green
- Light indicator:
- LED yellow
- Sensing distance adjustment:
- qTeach / 1-Step Teach-in
- Suppression of reciprocal influence:
- Yes
- Alignment optical axis:
- < 2°Light source=Pulsed red LED
- Wave length:
- 630 nm
- Response time / release time:
- < 1 ms
- Voltage supply range +Vs:
- 10 30 VDC
- Current consumption max. (no load):
- 45 mA
- Current consumption typ.:
- 30 mA
- Voltage drop Vd:
- <3 VDC
- Output function:
- Light / dark operate
- Output circuit:
- NPN complementary
- Output current:
- 100 mA
- Short circuit protection:
- Yes
- Reverse polarity protection:
- Yes
- Width / diameter:
- 12.9 mm
- Height / length:
- 32.3 mm
- Depth:
- 23 mm
- Design:
- Rectangular
- Housing material:
- Plastic (ASA, PMMA)
- Front (optics):
- PMMA
- Connection types:
- Cable 4 pin, 2 m
- Protection class:
- IP 67
- Operating temperature:
- -25 +60 °C
- Datasheet:
- View
