Baumer O500.DR-GM1J.72O

Baumer O500.DR-GM1J.72O

Baumer
SKU:
11233555
Availability:
Contact us to confirm availability and lead times.
$391.50
Condition:
New
Current Stock:
Description
The Baumer O500.DR-GM1J.72O is a high-precision distance measuring sensor with an IO-Link interface, designed for a measuring range of 60 to 600 mm. It features Teach-in and IO-Link for easy adjustment, and a pulsed PinPoint LED light source with a wavelength of 630 nm for optimal visibility. The sensor offers a resolution between 0.5 and 6 mm and maintains linearity with an error margin of ±3 to 20 mm. It is equipped with both green and yellow LED indicators for power and status alerts, respectively. The device operates efficiently with a response time of less than 1 ms and a low voltage drop of less than 3 VDC. It supports a voltage supply range of 10 to 30 VDC and has a maximum current consumption of 40 mA when idle. Safety features include short circuit and reverse polarity protection. The sensor's robust design includes a plastic housing made of ASA and PMMA, with a PMMA front optics, and it connects via an M12 4-pin connector. It is rated IP67 for protection against dust and water ingress, making it suitable for harsh environments. The compact dimensions are 18 mm in width, 45 mm in height, and 32 mm in depth, ensuring it fits in tight spaces. This sensor is ideal for applications requiring precise distance measurement and reliable operation in industrial settings.
Additional Information
Type:
Distance measuring
Version:
IO-Link measuring
Measuring distance Sd:
60 … 600 mm
Adjustment:
Teach-in and IO-Link
Power on indication:
LED green
Light indicator:
LED yellow
Resolution:
0.5 … 6 mm
Linearity error:
± 3 … 20 mm
Beam type:
Point
Suppression of reciprocal influence:
Yes
Alignment optical axis:
< 1°
Temperature drift:
< 0,2 % Sde/KLight source=Pulsed PinPoint LED
Wave length:
630 nm
Response time / release time:
< 1 ms
Voltage supply range +Vs:
10 … 30 VDC
Current consumption max. (no load):
40 mA
Voltage drop Vd:
<3 VDC
Output circuit:
Push-pull
Output current:
100 mA
Short circuit protection:
Yes
Reverse polarity protection:
Yes
Width / diameter:
18 mm
Height / length:
45 mm
Depth:
32 mm
Design:
Rectangular
Housing material:
Plastic (ASA, PMMA)
Front (optics):
PMMA
Connection types:
Connector M12 4 pin
Protection class:
IP 67
Operating temperature:
-25 … +60 °C
