Baumer OHDM 13N6901/S35A 10162724
Baumer
The Baumer OHDM 13N6901/S35A 10162724 is a high-precision sensor with background suppression and a sensing distance ranging from 50 to 550 mm. It features a pulsed red laser diode light source, with a beam diameter of 1 mm and a wavelength of 675 nm. This sensor is equipped with a green LED for power indication and a red LED for light indication. It offers flexible sensing distance adjustment through a teach-in method and operates with a quick response time of less than 5 ms and a release time of less than 15 ms. The sensor supports a voltage supply range of 12 to 28 VDC and includes safety features such as short circuit and reverse polarity protection. It has a compact, rectangular aluminum housing with glass optics, measures 13.4 mm in width, 48.2 mm in height, and 40 mm in depth, and is designed to withstand harsh environments with an IP 67 protection rating and an operating temperature range of 0 to +50 °C. The sensor connects via an M8 4-pin connector, ensuring easy integration into various applications.
