BT-LA-78M Mounting bracket

Leuze BT-LA-78M Mounting bracket

Leuze
SKU:
BT-LA-78M
Availability:
Factory stock
$774.00
Condition:
New
Current Stock:
Description
The Leuze BT-LA-78M is a rigid L-shaped mounting bracket designed for secure installation of LA-78M laser alignment aids and compatible protective sensors such as MLD safety devices. It features through-hole mounting at the system side and screw-type fastening at the device, typically suited for M3 screws, constructed from durable metal for reliable performance in industrial environments. This bracket enables precise positioning in alignment and safety applications, with RoHS compliance ensuring regulatory adherence. Documentation - Technical Datasheet: https://www.leuze.com/en-us/bt-la-78m/520021 - Product Page with Downloads: https://www.leuze.com/en-us/bt-la-78m-udc/520022 - Dimensioned Drawings: https://www.leuze.com/en-us/products/accessories/mounting-systems/mounting-brackets - CAD Models: https://www.leuze.com/en-us/downloads/cad/bt-la-78m
Additional Information
Suitable for product group:
Alignment aid,Protective sensors
Suitable for:
LA-78M laser alignment aids
Design of mounting device:
Angle, L-shape
Type of fastening, at system:
Groove mounting
Type of fastening, at device:
Screw type
Mounting device material:
Metal
Shock absorber:
No
Customs tariff number:
85389099
ECLASS 5.1.4:
27279202
ECLASS 8.0:
27279202
ECLASS 9.0:
27273701
ECLASS 10.0:
27273701
ECLASS 11.0:
27273701
ECLASS 12.0:
27273701
ECLASS 13.0:
27273701
ECLASS 14.0:
27273701
ECLASS 15.0:
27273701
ETIM 5.0:
EC002498
ETIM 6.0:
EC003015
ETIM 7.0:
EC003015
ETIM 8.0:
EC003015
ETIM 9.0:
EC003015
ETIM 10.0:
EC003015
Datasheet:
View
