Datasensing AE1/CN-4F Sensors
Datasensing
$52.16
The Datasensing AE1/CN-4F Sensors are designed for precision and reliability in industrial applications. These inductive sensors feature an M8 LD unshielded NC/NPN connection, ensuring seamless integration into your systems. With a nominal sensing distance of 4mm and an operating range of 0 to 3.24mm, they are ideal for detecting standard targets of 12x12mm FE360. The sensors boast a robust metal housing with IP67 protection, making them suitable for harsh environments. The 360° visible LED status indicator provides clear operational feedback, while the ATEX models cater to specific safety requirements.
Engineered for durability, these sensors offer complete protection against electrical damages, including short-circuit, reverse polarity, and impulsive overvoltage protection. They support a wide operating voltage range of 10 to 30Vdc and can handle load currents up to 200mA. The sensors are equipped with a yellow LED output state indicator and have a switching frequency of 5kHz, ensuring fast and accurate performance.
Constructed from nickel-plated brass with a PBT active head, the sensors are designed to withstand temperatures from -25°C to +70°C. They come with two M8x1 nuts for easy mounting and have been tested for vibration and shock resistance according to IEC standards. With CE and UR approvals, these sensors meet high safety and quality standards, making them a reliable choice for your proximity sensing needs.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,24mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,47 / aluminium: 0,52 / brass: 0,58 / stainless steel: 0,79
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M8 standard no-flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NC
- Switching frequency:
- 5kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M8 Plug
- Active Head Material:
- PBT
- Tightening torque:
- 3Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M8
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M8x1
- Mechanical Protection:
- IP67
