Datasensing AE6/CN-4F Sensors
Datasensing
$52.16
The Datasensing AE6/CN-4F Sensors are designed for precision and reliability in industrial applications. These inductive sensors feature a compact M8 short body housing, making them ideal for tight spaces. With a nominal sensing distance of 4mm and an operating range of 0 to 3.24mm, they are perfect for detecting standard targets of 12x12mm FE360. The sensors are equipped with a 360° visible LED status indicator for easy monitoring and are housed in durable nickel-plated brass, ensuring long-lasting performance.
These sensors offer complete protection against electrical damages, including short-circuit, reverse polarity, and impulsive overvoltage protection. They operate on a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and a load current of ? 200mA. The output type is NPN with a normally closed (NC) function, and they support a switching frequency of up to 5kHz.
The AE6/CN-4F Sensors are designed to withstand harsh environments, with an IP67 rating for dust and water resistance, and are compliant with EMC standards IEC 60947-5-2. They are also shock and vibration resistant, adhering to IEC 60068-2-6 and IEC 60068-2-27 standards. The sensors come with two M8x1 nuts for secure mounting and are suitable for operating temperatures ranging from -25°C to +70°C. Optional ATEX models for category 3 environments are available upon request.
- Nominal sensing distance:
- 4mm
- Operanting distance:
- 0 3,24mm
- Standard target:
- 12x12mm FE360
- Correction Factor:
- copper: 0,47 / aluminium: 0,52 / brass: 0,58 / stainless steel: 0,79
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M8 short case no-flush mount
- Functions:
- Proximity
- Output type:
- NPN
- Output Function:
- NC
- Switching frequency:
- 5kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Weight:
- 20g
- Housing Material:
- Nickel-plated brass
- Connections:
- M8 Plug
- Active Head Material:
- PBT
- Tightening torque:
- 3Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M8
- Approvals:
- CE UR
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 nuts M8x1
- Mechanical Protection:
- IP67
