Datasensing AH6/AN-4F Sensors

The Datasensing AH6/AN-4F Sensors are designed with extremely reduced dimensions, featuring a robust metal housing made from AISI303 stainless steel. These sensors are equipped with a 360° visible LED status indicator and offer IP67 protection, ensuring durability in various environments. They are available in both standard and long-distance models, with options for standard and short body housing. The sensors provide complete protection against electrical damages, including short-circuit, reverse polarity, and impulsive overvoltage protection. With a nominal sensing distance of 4mm and an operating distance of 0 to 3.24mm, these sensors are ideal for proximity functions. They feature an NPN output type with a normally open (NO) output function and a switching frequency of 5kHz. The sensors operate within a voltage range of 10 to 30Vdc, with a no-load supply current of ? 10mA and a load current of ? 200mA. The output voltage drop is minimal at ? 1.8V @200mA, and they maintain a low leakage current of ? 10?A. The sensors are designed for unshielded mounting and have a compact size with dimensions of Ø6.5mm and a length of 40mm, weighing only 5g. They are compatible with M8 plug connections and can operate in temperatures ranging from -25°C to +70°C. The active head material is made from PBT, ensuring reliable performance. These sensors are CE and UR approved, with EMC compatibility according to IEC 60947-5-2 standards, and are resistant to shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards.
