Datasensing AK6/BP-4H Sensors

The Datasensing AK6/BP-4H Sensors are designed for precision and reliability in various industrial applications. These inductive sensors feature a compact M18 short unshielded design with a nominal sensing distance of 12mm and an operating distance of 0 to 9.7mm. They are equipped with a PNP output type and offer both Normally Open (NO) and Normally Closed (NC) output functions, ensuring versatile performance. With a switching frequency of 2kHz and an operating voltage range of 10 to 30Vdc, these sensors are built to handle demanding environments. They boast a no-load supply current of ? 10mA and a load current capacity of ? 400mA, with a minimal output voltage drop of ? 1.5V at 400mA. The sensors are protected against short-circuits, reverse polarity, impulsive overvoltage, and inductive loads, ensuring durability and longevity. Constructed with a nickel-plated brass housing and an active head made of PBT, the sensors are robust and reliable, withstanding operating temperatures from -25°C to +70°C. They are IP67 rated for mechanical protection, making them resistant to dust and water ingress. The sensors come with M12 plug connections and include two M18x1 nuts for easy installation. The Datasensing AK6/BP-4H Sensors are CE and UR approved, with EMC compatibility according to IEC 60947-5-2 standards. They are designed to endure shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-27 standards, ensuring consistent performance in challenging conditions. With a thermal drift of Sr of less than 10% and a repeat accuracy of less than 5%, these sensors deliver reliable and accurate proximity detection.
