Datasensing AM6/CP-4HAN Sensors
Datasensing
$70.41
The Datasensing AM6/CP-4HAN Sensors are high-performance inductive sensors designed for precise proximity detection. Featuring an M12 unshielded short case, these sensors offer a nominal sensing distance of 8mm and an operating distance of 0 to 6.48mm, making them ideal for various industrial applications. The sensors are equipped with a PNP output type and a normally closed (NC) output function, ensuring reliable operation with a switching frequency of 2kHz.
Constructed with a robust nickel-plated brass housing and an active head made of PBT, these sensors are built to withstand harsh environments, offering mechanical protection rated at IP67. They are designed to operate within a temperature range of -25°C to +70°C and are resistant to shocks and vibrations as per IEC standards.
The AM6/CP-4HAN Sensors are equipped with advanced protection features, including short-circuit, reverse polarity, impulsive overvoltage, and protection against inductive loads. The sensors also feature a yellow LED indicator for output state, ensuring easy monitoring. With a low no-load supply current of ? 10mA and a load current capacity of ? 200mA, these sensors are energy-efficient and reliable.
The sensors are approved with CE and UR certifications and comply with EMC compatibility standards IEC 60947-5-2. They are supplied with two M12x1 nuts for easy installation and have a tightening torque of 10Nm. The sensors are compatible with a variety of materials, with correction factors for copper, aluminum, brass, and stainless steel, ensuring versatile application.
- Nominal sensing distance:
- 8mm
- Operanting distance:
- 0 6,48mm
- Standard target:
- 24x24mm FE360
- Correction Factor:
- copper: 0,41 / aluminium: 0,46 / brass: 0,52 / stainless steel: 0,71
- Thermal drift of Sr:
- < 10%
- Repeat Accuracy:
- < 5% (UB 24V Ta=23°C ±5°C)
- Hysteresis:
- 1 20%
- Description:
- M12 short case no-flush mount
- Functions:
- Proximity
- Output type:
- PNP
- Output Function:
- NC
- Switching frequency:
- 2kHz
- Operating Voltage:
- 10...30Vdc
- No-Load supply current:
- ? 10mA
- Load current:
- ? 200mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ? 1,8V @200mA
- Max ripple content:
- ? 10%
- LED indicators:
- Yellow LED output state
- Time delay before availability:
- ? 50ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Protection against inductive loads:
- Yes
- Mounting:
- Unshielded
- Housing Material:
- Nickel-plated brass
- Connections:
- M12 Plug
- Active Head Material:
- PBT
- Tightening torque:
- 10Nm
- Material:
- Nickel-plated brass
- Diameter/Dimension:
- M12
- Approvals:
- CE UR II 3G Ex nA IIC T6 Gc II 3D Ex tc IIIB T85°C Dc
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- 2 nuts M12x1
- Dimensions:
- M12 x 1 / L = 52,3mm
- Operating Temperature:
- -25°C +70°C
- Mechanical Protection:
- IP67
