Datasensing BS2/00-0C Sensors
Datasensing
$174.06
The Datasensing BS2/00-0C Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a diffuse reflection function with a nominal sensing distance of 100mm, these sensors are ideal for short-distance applications. The sensors offer a wide range of models, including diffuse, retro-reflective, and polarized options, ensuring versatility for various industrial needs.
Equipped with a multifunctional DECOUT® output, the sensors provide logic connection possibilities with selectable NPN/PNP and NO/NC output types. The sensitivity can be easily adjusted using a trimmer, allowing for fine-tuning to suit specific requirements. With a high switching frequency of 80Hz and a rapid response time of 6.25ms, these sensors ensure quick and accurate performance.
The BS2/00-0C Sensors are designed for durability and reliability, featuring a robust ABS housing and a completely resin-filled construction for enhanced protection. They are equipped with LED status indicators for easy monitoring and offer short-circuit and reverse polarity protection for added safety. The sensors operate within a wide voltage range of 10 to 30VDC and have a low no-load supply current of ? 25mA.
With an IP65 degree of protection, these sensors are suitable for use in challenging environments, withstanding temperatures from -25°C to +70°C without freezing. The sensors come with a standard 2m PVC cable with a 90° exit, and optional M12 plug exit, providing flexibility in installation. Supplied with ST01 mounting brackets and screws, the Datasensing BS2/00-0C Sensors are ready for seamless integration into your system.
- Nominal sensing distance:
- 100mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Optic position:
- Axial
- Output type:
- Decout NPN/PNP Selectable NO/NC Selectable
- Output Function:
- NO/NC Selectable
- Switching frequency:
- 80Hz
- Response time:
- 6,25ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status)
- Time delay before availability:
- 200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 185g
- Housing Material:
- ABS
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-29
- Degree of protection:
- IP65
- Supplied Accessories:
- ST01 mounting brakets and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
