Datasensing C18P/BN-2E Sensors
Datasensing
$131.09
The Datasensing C18P/BN-2E Sensor is a high-performance capacitive sensor designed for precision and reliability. Featuring an M18 plastic unshielded design, this sensor operates with a DC supply voltage and offers a nominal sensing distance of 3 to 12mm. It boasts high noise immunity and adjustable sensitivity, making it suitable for various industrial applications. The sensor is equipped with NPN output type and NO + NC output functions, ensuring versatile connectivity options. With a switching frequency of 50Hz and an operating voltage range of 10 to 40Vdc, it delivers consistent performance. The sensor's plastic housing and polyester active head material provide durability, while its IP67 and IP68 protection ratings ensure resilience against harsh environments. Additional features include short-circuit protection, reverse polarity protection, and impulsive overvoltage protection. The sensor is easy to install with its M12 plug connection and comes with supplied accessories such as a screwdriver and two M18 nuts. Ideal for use in temperatures ranging from -35°C to +85°C, this sensor is CE cULus approved and EMC compatible, making it a reliable choice for demanding applications.
- Nominal sensing distance:
- 3 12mm
- Thermal drift of Sr:
- < 20%
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Yes
- Hysteresis:
- ? 20%
- Output type:
- NPN
- Output Function:
- NO + NC
- Switching frequency:
- 50Hz
- Operating Voltage:
- 10...40Vdc
- No-Load supply current:
- ? 12mA
- Load current:
- ? 200mA
- Leakage current:
- ? 100µA
- Output voltage drop:
- ? 2,5V @ IL = 200mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow LED (object detected)
- Time delay before availability:
- ? 200ms
- Short-circuit protection:
- polarity reversal, overvoltage
- Reverse Polarity Protection:
- Yes
- Impulsive Overvoltage Protection:
- Yes
- Mounting:
- Unshielded
- Weight:
- 65g
- Housing Material:
- Polyester
- Connections:
- M12 plug
- Active Head Material:
- Polyester
- Tightening torque:
- 2,6Nm
- Storage temperature:
- -40°C +85°C
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- IEC 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67, IP68
- Supplied Accessories:
- screw driver, 2 x M18 nuts
- Mechanical Protection:
- IP67, IP68
