Datasensing FAI4/BN-2A Sensors
Datasensing
$97.02
The Datasensing FAI4/BN-2A Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring a 90° diffuse reflection principle, these sensors offer a nominal sensing distance of 200mm, making them ideal for short-distance applications. With a robust M18 housing available in both metallic and plastic options, they ensure durability and versatility in various environments. The sensors operate on a 10...30 VDC power supply and are equipped with NPN NO+NC output functions, providing flexibility in integration.
Engineered for high performance, the FAI4/BN-2A Sensors include sensitivity adjustment via a trimmer, allowing for fine-tuning to suit specific needs. They boast a fast switching frequency of 250Hz and a quick response time of 2ms, ensuring efficient operation. The sensors are protected against short circuits, overvoltage, and reverse polarity, offering total protection against electric damages.
With an IP67 protection degree, these sensors are resistant to dust and water, making them suitable for harsh industrial environments. They are also CE and cULus listed, ensuring compliance with international safety standards. The sensors come with a 2m PVC cable for easy installation and are equipped with LED indicators for clear status visibility. Ideal for detecting transparent objects, they feature retro-reflective models with red emission and are compatible with a wide range of applications.
- Nominal sensing distance:
- 200mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT/ PC cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
