Datasensing FAI6/BN-1E Sensors
Datasensing
$76.31
The Datasensing FAI6/BN-1E Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an axial diffuse reflection principle, these sensors offer a nominal sensing distance of 400mm, making them ideal for medium-distance applications. With a robust nickel-plated brass housing and IP67 protection, they are built to withstand harsh environments. The sensors operate on a 10...30 VDC power supply and provide NPN NO+NC output functions, ensuring versatile integration into various systems.
Equipped with LED infrared emission at 880nm, they effectively detect transparent objects with a high degree of accuracy, supported by a repeat accuracy of 5%. The sensors are designed to handle a wide range of operating temperatures from -25°C to +70°C, without freezing, and are protected against short circuits, overvoltage, and reverse polarity.
The M18 sensors come with an M12 connection plug and are easy to install with supplied M18 x 1 nuts. They feature a quick response time of 2ms and a switching frequency of 250Hz, making them suitable for fast-paced industrial applications. The sensors are CE and cULus listed, ensuring compliance with international safety standards. With their compact dimensions and lightweight design, the Datasensing FAI6/BN-1E Sensors are a reliable choice for efficient and accurate sensing solutions.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
