Datasensing FAI7/BP-0AVE80 Sensors
Datasensing
$110.88
The Datasensing FAI7/BP-0AVE80 Sensors are advanced photoelectric sensors designed for precise and reliable detection. Featuring an M18 axial diffuse design, these sensors offer a nominal sensing distance of 400mm, making them ideal for medium-distance applications. With a PNP NO+NC output type, they provide versatile switching options. The sensors are equipped with a sensitivity adjustment trimmer, allowing for fine-tuning to suit specific needs. Constructed with a durable plastic housing and a 200mm PVC cable with an M12 plug, they ensure easy installation and connectivity.
These sensors operate on a 10
30VDC power supply and are designed to withstand challenging environments, with an IP67 protection rating against dust and water ingress. They are equipped with LED indicators for easy status monitoring and offer robust protection features, including short-circuit, overvoltage, and reverse polarity protection. The sensors are capable of handling a load current of up to 100mA and have a fast response time of 2ms, ensuring quick and accurate performance.
Ideal for detecting transparent objects, the FAI7/BP-0AVE80 Sensors utilize LED infrared emission at 880nm and are resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from sunlight. With approvals from CE and cULus, these sensors meet high safety and quality standards, making them a reliable choice for various industrial applications.
- Nominal sensing distance:
- 400mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Notes:
- white target Kodak 90% 200 x 200mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 50g
- Housing Material:
- PBT / PC cable exit
- Connections:
- 200mm PVC cable + M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
