The Datasensing FAID/BP-0EAN Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 20 meters, these sensors feature a PNP NO+NC output type, ensuring versatile application capabilities. The robust metal M12 connector and IP67-rated housing provide excellent protection against dust and water, making them suitable for challenging environments.
Engineered with a thermal drift of Sr ?10% and a repeat accuracy of 5%, these sensors guarantee consistent performance. The sensitivity can be easily adjusted using a trimmer, and the sensors operate efficiently with a switching frequency of 250Hz and a response time of just 2ms. They support an operating voltage range of 10 to 30VDC, with a no-load supply current of ? 25mA and a load current of ?100mA.
The FAID/BP-0EAN Sensors are equipped with LED infrared emission at 880nm, providing reliable detection even in high ambient light conditions up to 10,000 lux. The sensors are protected against short circuits, overvoltage, and reverse polarity, ensuring durability and longevity.
Constructed with a PBT/PC plug housing and a PC active head, these sensors are designed to withstand mechanical shocks and vibrations as per IEC standards. They come with supplied accessories, including M18 x 1 nuts and a screwdriver, for easy installation. With CE and cULus Ex approvals, these sensors meet stringent safety and performance standards, making them an ideal choice for industrial automation applications.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (Lon) or output status Lo/Do
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus Ex: II 3G Ex nA IIC T6 Gc II 3D Ex tc IIIB T85°C Dc
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Dimensions:
- M18 x 1 /L =81,6mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
