Datasensing FAIH/00-0E Sensors
Datasensing
$51.86
The Datasensing FAIH/00-0E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring an axial emitter with a nominal sensing distance of 20 meters, these sensors are ideal for a variety of applications. The robust M18 design is equipped with a plastic housing and a convenient M12 connection, ensuring easy integration into existing systems. With a power supply range of 10 to 30 VDC, these sensors offer flexibility and adaptability.
Engineered for durability, the FAIH/00-0E Sensors boast an IP67 protection degree, safeguarding against dust and water ingress. The sensors are equipped with LED infrared emission at 880nm, providing reliable performance even in challenging environments. The yellow LED indicator ensures clear visibility of the power status, while the reverse polarity protection and impulsive voltage safeguards enhance operational safety.
The sensors are designed to withstand extreme temperatures, operating efficiently between -25°C and +70°C without freezing. With a repeat accuracy of 5% and a switching frequency of 250Hz, these sensors deliver consistent and accurate results. The compact dimensions of M18 x 1 with a length of 81.6mm and a weight of just 30g make them easy to handle and install.
Approved by CE and cULus, and compliant with EMC compatibility standards EN 60947-5-2, the Datasensing FAIH/00-0E Sensors are a reliable choice for detecting transparent objects with retro-reflective models. The sensors come with supplied accessories, including M18 x 1 nuts, ensuring a secure and stable installation. Whether for industrial automation or other demanding applications, these sensors provide total protection against electric damages and are built to endure shocks and vibrations as per IEC standards.
- Nominal sensing distance:
- 20m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Infrared (880nm)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
