Datasensing FAL4/BN-2E Sensors
Datasensing
$289.21
The Datasensing FAL4/BN-2E Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a 90° laser diffuse reflection with a nominal sensing distance of 200mm, these sensors are perfect for short-distance applications. The sensors operate on a 10...30 Vdc power supply and offer both NPN NO+NC output functions, ensuring versatile integration into various systems.
With a robust IP67 protection rating, these sensors are built to withstand harsh environments, offering total protection against electric damages. The housing is available in both metallic and plastic options, with a radial optic position for optimal performance. Sensitivity adjustment is made easy with the teach-in function, allowing for precise calibration.
The FAL4/BN-2E Sensors boast a high switching frequency of 800Hz and a rapid response time of 625µs, making them ideal for fast-paced industrial applications. They are equipped with LED indicators for easy status monitoring and feature comprehensive protection mechanisms, including short-circuit, overvoltage, and reverse polarity protection.
These sensors are CE and cULus listed, ensuring compliance with international safety standards. They are also designed to resist interference from external light sources, withstanding up to 3000lux from incandescent lamps and 10000lux from sunlight. The compact M18 x 1 dimensions and lightweight design (30g) make installation straightforward, with supplied accessories including M18 nuts and a screwdriver for convenience.
Operating efficiently in temperatures ranging from -15°C to +55°C, the Datasensing FAL4/BN-2E Sensors are a reliable choice for a wide range of industrial sensing applications.
- Nominal sensing distance:
- 200mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Teach-in
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- (focalized 100mm) white target 90% Kodak 200x200mm
- Optic position:
- Radial 90°
- Output type:
- NPN NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 800Hz
- Response time:
- 625µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green power supply/yellow (LightON EG?2)/yellow flashing (LightON 1
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LASER Red (650nm) class1
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- Glass / PC
- Tightening torque:
- 1Nm
- Operating temperature:
- -15°C...+ 55°C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 15°C...+ 55°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
