Datasensing FQR3/BP-0E Sensors
Datasensing
$91.78
The Datasensing FQR3/BP-0E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring an axial diffuse reflection principle, these sensors offer a nominal sensing distance of 100mm, making them ideal for detecting white targets like Kodak 90% 100 x 100mm. With a robust PBT/PC housing and IP67 protection, they are built to withstand harsh environments, ensuring complete protection against electrical damages and mechanical impacts.
Equipped with a PNP NO+NC output type, the FQR3/BP-0E Sensors provide complementary output functions, allowing for versatile integration into existing systems. The sensors boast a high switching frequency of 250Hz and a rapid response time of 2ms, ensuring quick and accurate detection. The sensitivity can be easily adjusted using a trimmer, and the sensors are protected against short circuits, overvoltage, and reverse polarity, enhancing their durability and longevity.
Operating within a voltage range of 10
30VDC, these sensors maintain a low no-load supply current of ?30mA and a load current of ?50mA, making them energy-efficient. The LED indicators provide clear status output, while the M12 plug connection ensures easy installation. With approvals from CE and compliance with EMC compatibility standards, the Datasensing FQR3/BP-0E Sensors are a reliable choice for any industrial sensing application.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?50mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2V@Iload=50mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Short circuit (autoreset), Overvoltage
- Reverse Polarity Protection:
- Polarity inversal, Inpulsive voltage
- Emission:
- LED Red (660nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Weight:
- 20g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PC
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
