Datasensing HEE/00-4A Sensors
Datasensing
$89.52
The Datasensing HEE/00-4A Sensors are high-performance photoelectric sensors designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency and a nominal sensing distance of 2 meters. The robust stainless steel housing ensures durability, while the IP67 protection degree offers complete protection against electrical damages and environmental factors.
Equipped with a yellow LED status indicator for power ON, these sensors operate on a supply voltage of 10 to 30 VDC and have a no-load supply current of ?45mA. The emitter function principle, with an axial optic position, ensures accurate detection, and the LED infrared emission at 880nm provides reliable performance even in challenging lighting conditions, with interference resistance up to 3,000 lux from incandescent lamps and 5,000 lux from sunlight.
The HEE/00-4A Sensors are designed with user safety in mind, featuring short-circuit and reverse polarity protection, as well as impulsive overvoltage protection. The sensors are CE approved and EMC compatible with EN 60947-5-2 standards, ensuring compliance with industry regulations.
With a compact design of M8x0.75/L=49mm and a lightweight of 40g, these sensors are easy to install and integrate into various applications. The 2-meter PVC cable connection and supplied M8 x 0.75 nuts facilitate straightforward setup. Operating efficiently in temperatures ranging from -25°C to +70°C, the Datasensing HEE/00-4A Sensors are the ideal choice for reliable and precise sensing solutions.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Emitter
- Notes:
- (EG=2)
- Emitter/Receiver:
- Emitter
- Optic position:
- Axial
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (powerON)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 40g
- Housing Material:
- Stainless Stee AISI 303l / PA12 cable exit
- Connections:
- 2m PVC cable
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
