Datasensing HER/AP-4F Sensors
Datasensing
$146.64
The Datasensing HER/AP-4F Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. Featuring an M8 through beam model, these sensors boast a high switching frequency of 1Khz and a nominal sensing distance of 2 meters. The robust stainless steel housing ensures durability, while the IP67 protection degree offers complete protection against electrical damages and environmental factors. With a supply voltage range of 10 to 30 VDC, these sensors are equipped with a PNP NO output type and a yellow LED status indicator for easy monitoring.
The HER/AP-4F Sensors are engineered with advanced features such as short-circuit and reverse polarity protection, ensuring safe and efficient operation. The sensors are designed to withstand external light interference up to 3,000 lux from incandescent lamps and 5,000 lux from sunlight, making them suitable for various industrial applications. The compact design, with dimensions of M8x0.75/L=49mm and a weight of just 15g, allows for easy integration into existing systems.
These sensors are CE approved and comply with EMC compatibility standards EN 60947-5-2, ensuring high-quality performance and reliability. The operating temperature range of -25°C to +50°C (without freeze) makes them versatile for different environments. Supplied with M8 x 0.75 nuts, the Datasensing HER/AP-4F Sensors are ready for immediate installation and use.
- Nominal sensing distance:
- 2m
- Thermal drift of Sr:
- ?10%Sr
- Repeat Accuracy:
- ?10%
- Sensitivity adjustment:
- No
- Function Principle:
- Receiver
- Notes:
- (EG=2)
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- PNP NO
- Output Function:
- NO
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ?45mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3.000 lux (incandescent lamp), 5.000 lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Dimensions:
- M8x0,75/L=49mm
- Weight:
- 15g
- Housing Material:
- Stainless Steel AISI 303
- Connections:
- M8 plug 3pin
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 50° C (without freeze)
- Diameter/Dimension:
- M8
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M8 x 0,75
- Dimensions:
- M8x0,75/L=54mm
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
