Datasensing PS2/CN-0C Sensors
Datasensing
$182.35
The Datasensing PS2/CN-0C Sensors are compact photoelectric sensors designed for precise and reliable detection. With a nominal sensing distance of 100mm, these sensors utilize diffuse reflection technology for short-distance applications up to 200mm. The sensors feature a trimmer for sensitivity adjustment, allowing for tailored performance in various environments.
Equipped with an NPN NC output type, the PS2/CN-0C sensors offer a switching frequency of 100Hz and a rapid response time of 5ms, ensuring quick and accurate detection. The sensors operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 30mA and a load current capacity of ?100mA.
Designed for durability, these sensors boast an IP65 protection rating, safeguarding against dust and water ingress. They are also equipped with short-circuit and reverse polarity protection, enhancing their reliability in challenging conditions. The LED status indicator provides a clear visual of the output state, while the robust ABS housing and PMMA active head material ensure longevity.
The PS2/CN-0C sensors are resistant to external light interference, withstanding up to 3000lux from incandescent lamps and 10000lux from other sources. They are compliant with CE and EMC standards, ensuring compatibility and safety. Supplied with an ST07 mounting bracket and screws, these sensors are easy to install and integrate into existing systems.
Ideal for applications requiring high precision and compact design, the Datasensing PS2/CN-0C Sensors are a reliable choice for various industrial and automation needs.
- Nominal sensing distance:
- 100mm
- Thermal drift of Sr:
- ? 10% Sr
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Optic position:
- Axial
- Output type:
- NPN NC
- Output Function:
- NC
- Switching frequency:
- 100Hz
- Response time:
- 5ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A @ Vmax
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- red (output state)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 90g
- Housing Material:
- ABS
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP65
- Supplied Accessories:
- ST07 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
