Datasensing PS4/AN-0E Sensors
Datasensing
$196.94
The Datasensing PS4/AN-0E Sensors are compact and versatile photoelectric sensors designed for precise detection tasks. With a nominal sensing distance of 200mm, these sensors utilize diffuse reflection technology, making them ideal for short-distance applications. The sensors feature a trimmer for sensitivity adjustment, allowing for fine-tuning to suit specific needs.
Equipped with an NPN NO output type, the PS4/AN-0E sensors offer a high switching frequency of 100Hz and a rapid response time of 5ms, ensuring quick and reliable performance. The sensors operate within a voltage range of 10 to 30VDC, with a no-load supply current of ? 30mA and a load current capacity of ?100mA.
Designed with durability in mind, these sensors boast an IP66 protection degree, safeguarding against dust and water ingress. The robust ABS housing and PMMA active head material ensure longevity, even in challenging environments. The sensors are equipped with LED indicators for easy status monitoring and feature comprehensive protection against electrical damage, including short-circuit and reverse polarity protection.
The compact dimensions of 15x49x26mm and a weight of 90g make these sensors easy to install, with an M12 plug 90° connection for seamless integration. The PS4/AN-0E sensors are CE approved and EMC compatible, adhering to EN 60947-5-2 standards. They come with supplied accessories, including an ST07 mounting bracket and screws, for hassle-free setup.
Ideal for applications requiring high precision and reliability, the Datasensing PS4/AN-0E Sensors are a dependable choice for various industrial and automation tasks.
- Nominal sensing distance:
- 200mm
- Thermal drift of Sr:
- ? 10% Sr
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (short distance, ?200mm)
- Optic position:
- Axial
- Output type:
- NPN NO
- Output Function:
- NO
- Switching frequency:
- 100Hz
- Response time:
- 5ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ? 10?A @ Vmax
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- red (output state)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Weight:
- 90g
- Housing Material:
- ABS
- Connections:
- M12 plug 90°
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP66
- Supplied Accessories:
- ST07 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP66
