Datasensing QX3/A0-1F Sensors
Datasensing
$190.12
The Datasensing QX3/A0-1F Sensors are advanced photoelectric sensors designed for precision and reliability. Featuring a diffuse reflection function with a nominal sensing distance of 300mm, these sensors are equipped with axial optics for medium-distance detection up to 600mm. The QX3/A0-1F model boasts a fast response time of 666µs and a high switching frequency of 750Hz, ensuring quick and accurate detection in various applications.
With selectable NPN/PNP output types and a high output current capacity of over 300mA, these sensors offer flexibility and robust performance. The visible red light in retro-reflective, polarized, and through-beam models enhances detection capabilities over long distances. The precision beam and sensitivity adjustment via a trimmer allow for fine-tuning in diverse environments.
Built with durability in mind, the sensor features a rugged ABS housing and an acrylic active head, providing IP65 mechanical protection against dust and water. It operates efficiently within a temperature range of -25°C to +70°C, making it suitable for challenging conditions. The sensor is equipped with LED indicators for output status and stability, ensuring easy monitoring and maintenance.
The QX3/A0-1F model includes short-circuit and reverse polarity protection, along with EMC compatibility per EN 60947-5-2 standards, ensuring reliable operation in industrial settings. Supplied with ST70 mounting brackets and screws, this sensor is ready for seamless integration into your system.
- Nominal sensing distance:
- 300mm
- Repeat Accuracy:
- ? 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (medium distance, ?600mm)
- Optic position:
- Axial
- Output type:
- NPN/PNP Selectable NO
- Output Function:
- NO
- Switching frequency:
- 750Hz
- Response time:
- 666µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 20mA
- Load current:
- ?300mA
- Leakage current:
- ? 100?A @ 30Vdc
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Red(output status) , Geen (stability)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux Incandescent Lamp, 10000lux
- Dimensions:
- 15x23x42
- Weight:
- 70g
- Connections:
- M8 plug 4pin
- Active Head Material:
- Acrylic
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Material:
- ABS
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST70 mounting brakets and screws
- Dimensions:
- 15x23x40
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
