Datasensing QXX/00-1E Sensors

The Datasensing QXX/00-1E Sensors are advanced photoelectric sensors designed for precision and reliability in various industrial applications. Featuring axial and right-angle optics, these sensors are equipped with two LED indicators for threshold and signal margin, ensuring optimal performance. The visible red light is available in retro-reflective, polarized, and through-beam models, offering long-distance capability and a precision beam for accurate detection. With a fast response time of 0.75-0.5 ms and a selectable NPN-PNP output, these sensors provide high output current exceeding 300 mA. The nominal sensing distance is 8 meters, with a repeat accuracy of ? 5% and sensitivity adjustment via a trimmer. The emitter function principle and axial optic position enhance the sensor's efficiency. Operating on a voltage range of 10 to 30 VDC, the QXX/00-1E sensors have a no-load supply current of ? 20 mA and an output voltage drop of ? 1.2 V at a load current of 100 mA. They are designed with short-circuit and reverse polarity protection, ensuring durability and safety in demanding environments. The sensors emit LED infrared light at 880 nm and can withstand interference from external light sources up to 3000 lux from incandescent lamps and 10000 lux from other sources. With dimensions of 15x23x89 mm and a weight of 70 g, the sensors are housed in durable ABS material with an acrylic active head. They are compatible with M12 plug connections and come with ST70 mounting brackets and screws for easy installation. The QXX/00-1E sensors are CE approved and meet EMC compatibility standards EN 60947-5-2. They are designed to withstand shocks and vibrations as per IEC 60068-2-6 and IEC 60068-2-28 standards, with an IP65 degree of protection. Operating temperatures range from -25°C to +70°C without freezing, making them suitable for various industrial environments.
