Datasensing RXS/00-3B Sensors
Datasensing
$202.06
The Datasensing RXS/00-3B Sensors are designed for precision and versatility, offering a range of models including diffuse reflection, retro-reflective, polarized, through-beam, and background suppression. These sensors boast high performance with a nominal sensing distance of 0.3m and a compact design, making them ideal for various installation scenarios. Equipped with a relay output or multifunctional DECOUT®, they feature a timer function with delay on, delay off, and one-shot capabilities, along with a trimmer for sensitivity adjustment. The sensors include a switch to reduce emission for fine detection in through-beam types and an LED alignment indicator with 360° visibility, ensuring easy setup and operation.
The RXS/00-3B Sensors are built to withstand challenging environments, with a robust PC housing and PMMA active head material, offering IP65 mechanical protection. They operate efficiently within a temperature range of -25°C to +70°C and are protected against reverse polarity and impulsive overvoltage. The sensors are compatible with M12 plug connections and come with supplied accessories, including an ST81 mounting bracket and screws. With approvals such as CE and EMC compatibility with EN 60947-5-2, these sensors are reliable and durable, suitable for a wide range of industrial applications.
- Nominal sensing distance:
- 0,3m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Minimum sensing distance (blind zone):
- 0,05m
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 200 x 200mm EG=1,5
- Optic position:
- Axial
- Output type:
- Relay SPST NO/NC
- Output Function:
- NO/NC
- Switching frequency:
- 25Hz
- Response time:
- 20ms
- Operating Voltage:
- 20...60VDC /20...253VAC/50-60Hz
- No-Load supply current:
- ? 30mARMS
- Load current:
- 3A-250Vac/3A-30Vdc (750VA/90W)
- Max ripple content:
- ?10%
- LED indicators:
- Red (output status) o (alineament), Green (stability)
- Time delay before availability:
- ?200ms
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- ? 5000lux (incandescent lamp)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 90g
- Housing Material:
- PC
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Operating temperature:
- - 25°C + 70°C ( without freeze)
- Diameter/Dimension:
- Cubic
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-28
- Degree of protection:
- IP65
- Supplied Accessories:
- ST81 mounting bracket and screws
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP65
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
- User Manuals:
- View
