Datasensing SAP/0N-0C Sensors
Datasensing
$152.24
The Datasensing SAP/0N-0C Sensors are advanced photoelectric sensors designed for precision and reliability. With a nominal sensing distance of 6 meters and a thermal drift of Sr at 10%, these sensors ensure accurate detection in various applications. The polarized function principle, combined with a sensitivity adjustment trimmer, allows for customizable performance tailored to specific needs.
Equipped with a double LED indicator for power and status output, the sensors provide clear visual feedback. The NPN L/D selectable output function offers flexibility in integration, while the IP65 protection degree ensures durability in challenging environments. The sensors are built with a robust PBT housing and a PMMA active head, providing excellent resistance to shocks and vibrations as per IEC standards.
The SAP/0N-0C Sensors operate efficiently within a voltage range of 10 to 30VDC, with a low no-load supply current of ? 30mA and a load current of ?100mA. They feature short-circuit and reverse polarity protection, ensuring safe and reliable operation. The sensors are compatible with a wide range of plugs, accessories, and reflectors, making them versatile for various industrial applications.
With approvals from CE and EMC compatibility with EN 60947-5-2, these sensors meet high standards of quality and safety. The compact dimensions of 21.4mm x 89.8mm and a weight of 75g make them easy to install, while the 2m PVC cable with a 90° exit provides convenient connectivity. Operating effectively in temperatures ranging from -25°C to +70°C, the Datasensing SAP/0N-0C Sensors are an ideal choice for reliable and efficient sensing solutions.
- Nominal sensing distance:
- 6m
- Thermal drift of Sr:
- 10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Polarized
- Notes:
- On RL110 reflector
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10µA
- Output voltage drop:
- ?2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Green (powerON), Yellow (Status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3.000lux (incandescent lamp), 10.000lux (sunlight)
- Weight:
- 75g
- Housing Material:
- PBT / Nylon cable exit
- Connections:
- 2m PVC cable 90°
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- Nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
