Datasensing SH4/E-1EIC Sensors
Datasensing
$135.84
The Datasensing SH4/E-1EIC Sensors are advanced safety sensors designed for high-performance industrial applications. Featuring a robust M18 metal housing, these sensors offer a nominal sensing distance of 10 meters with an axial optic configuration. They are compliant with EN50100 Category 2 and Category 4 standards, ensuring reliable safety performance. The sensors are equipped with LED indicators for easy status monitoring and are compatible with any safety module that adheres to IEC61131-2 standards. With a single-beam resolution and an effective aperture angle of ? ±2.5°, these sensors provide precise detection capabilities. They operate within a voltage range of 10 to 30 Vdc and have a no-load supply current of ? 25mA. The SH4/E-1EIC Sensors are designed to withstand harsh environments, with an operating temperature range of -20°C to +55°C and a degree of protection rated at IP67. They are approved by CE and TÜV, ensuring compliance with international safety standards. Please note that these sensors should not be used with the SBCR03 control unit and require an external safety control unit with an automatic optics test function for optimal performance.
- Nominal sensing distance:
- 10m (ExG=4)
- Thermal drift of Sr:
- ? 10%
- Resolution:
- Single-beam
- controlled height:
- Single-beam
- Effective Aperture Angle:
- ? ±2,5°
- Effective Aperture Angle:
- Typical ±1,8°
- Function Principle:
- Emitter
- Notes:
- not working with SBCR03 control unit. To be used with external safety control unit with automatic optics test function
- Description:
- M18 Type 4 Safety Photocell Emitter
- Type:
- Type 4 safety photocell
- SIL:
- 3
- SILCL:
- 3
- PL:
- e
- PFHd:
- 8,10E-10
- MTTFd:
- 20 years
- Operating Voltage:
- 10 30 Vdc
- No-Load supply current:
- ? 25mA
- Max ripple content:
- ? 5 Vpp
- LED indicators:
- Yellow (power)
- Emission:
- Red
- Test levels:
- <5V emission inactive >15V emission active
- Housing Material:
- PBT
- Connections:
- M12 plug
- Active Head Material:
- Glass
- Operating temperature:
- -20°C +55°C
- Storage temperature:
- -40°C +75°C
- Approvals:
- CE, TÜV
- Shocks and vibrations:
- 10g - 16ms (according to IEC600068-2-29) 10Hz 55Hz - 1 oct/min - 0,35mm (according to 60068-2-6)
- Degree of protection:
- IP67
- Supplied Accessories:
- 2 x nuts
- Operating Temperature:
- -20 +55°C (Without freeze)
- Mechanical Protection:
- IP67
