Datasensing SS0/LP-0E Sensors
Datasensing
$107.78
The Datasensing SS0/LP-0E Sensors are advanced photoelectric sensors designed for precise detection with a nominal sensing distance of 50mm. Featuring a robust IP67 protection degree, these sensors are built to withstand harsh environments and provide complete protection against electrical damages. The models come with side sensor adjustment on both axial and right-angle optics, offering flexibility in installation. The sensors are equipped with a PNP Lon output type and a selectable LO/DO output function, ensuring compatibility with various applications.
With a high switching frequency of 1kHz and a rapid response time of 500µs, the SS0/LP-0E Sensors deliver quick and accurate performance. The sensors are designed with a background suppression function principle, making them ideal for detecting objects as small as 1mm. The LED status indicator provides clear visibility of the sensor's operational status, while the red LED emission at 660nm ensures reliable detection.
These sensors are engineered with a durable PBT housing and a PMMA active head material, ensuring longevity and reliability. The M12 plug connection facilitates easy integration into existing systems. The sensors are CE and cULus listed, meeting international safety and performance standards. Additionally, ATEX models, category 3, are available upon request for use in potentially explosive atmospheres.
The Datasensing SS0/LP-0E Sensors are designed to operate efficiently within a temperature range of -25°C to +70°C, without freezing, and are resistant to shocks and vibrations as per IEC standards. With features like short-circuit protection, reverse polarity protection, and impulsive overvoltage protection, these sensors are a reliable choice for various industrial applications.
- Nominal sensing distance:
- 50mm
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- minimum detectable object:
- 1mm
- Sensitivity adjustment:
- No
- Function Principle:
- Blackground suppression
- Notes:
- white target Kodak 90% 100 x 100mm
- Optic position:
- Axial
- Output type:
- PNP Lon
- Output Function:
- Lon
- Switching frequency:
- 1Khz
- Response time:
- 500µs
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Red (660nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
