Datasensing SS8/0P-1E Sensors
Datasensing
$107.75
The Datasensing SS8/0P-1E Sensors are advanced photoelectric sensors designed for precise and reliable detection. With a nominal sensing distance of 1 meter and a diffuse reflection function principle, these sensors are ideal for long-distance applications exceeding 600mm. The sensors feature a side sensitivity adjustment on both axial and right-angle optics, allowing for flexible installation and operation. The output type is PNP with L/D selectable functionality, providing versatility in various applications.
Equipped with a robust IP67 protection degree, these sensors are safeguarded against electrical damages and environmental factors, ensuring durability and longevity. The LED status indicator provides clear visibility of the sensor's operational status, while the short-circuit and reverse polarity protection enhance safety and reliability.
The SS8/0P-1E Sensors are designed to withstand harsh conditions, with an operating temperature range of -25°C to +70°C and resistance to shocks and vibrations as per IEC standards. The nickel-plated brass housing and PMMA active head material contribute to the sensor's rugged construction.
Additional features include a high switching frequency of 250Hz, a fast response time of 2ms, and a low no-load supply current of ?30mA. The sensors are compatible with M12 plug connections and come with supplied accessories such as M18 x 1 nuts and a screwdriver for easy installation.
Approved by CE and cULus, and compliant with EMC compatibility standards, the Datasensing SS8/0P-1E Sensors are a reliable choice for industrial applications requiring precise and adaptable sensing solutions.
- Nominal sensing distance:
- 1m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse reflection (long distance, >600mm)
- Notes:
- white target Kodak 90% 400 x 400mm
- Optic position:
- Axial
- Output type:
- PNP L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?1,2V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 3000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
- 2D Files:
- View
- 3D Files:
- View
- CAD Files:
- View
- EU Declarations:
- View
- Catalog:
- View
