Datasensing SSD/0N-0E Sensors
Datasensing
$82.59
The Datasensing SSD/0N-0E Sensors are advanced photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 14 meters, these sensors feature a trimmer for sensitivity adjustment, ensuring optimal performance in various applications. The NPN L/D selectable output function allows for versatile integration, while the axial optic position enhances detection accuracy. Operating at a switching frequency of 250Hz and a response time of just 2ms, these sensors are ideal for high-speed operations.
Built to withstand challenging environments, the SSD/0N-0E Sensors offer complete protection against electrical damages, including short-circuit and reverse polarity protection. The robust housing, made from PBT and PC plug materials, ensures durability, while the IP67 protection degree guarantees resistance to dust and water ingress. The sensors are equipped with LED infrared emission at 880nm, providing reliable performance even in high ambient light conditions, with interference resistance up to 5000lux for incandescent lamps and 10000lux for sunlight.
The compact design, with dimensions of M18 x 1 and a length of 78mm, makes installation straightforward, complemented by the M12 plug connection. The sensors come with supplied accessories, including M18 x 1 nuts and a screwdriver, for easy setup. Approved by CE and cULus, and compliant with EMC compatibility standards EN 60947-5-2, these sensors are a dependable choice for industrial applications requiring precise and consistent sensing capabilities.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 30g
- Housing Material:
- PBT / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 1Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
