Datasensing SSD/0N-1E Sensors
Datasensing
$88.82
The Datasensing SSD/0N-1E Sensors are high-performance photoelectric sensor receivers designed for precision and reliability. With a nominal sensing distance of 14 meters, these sensors feature a trimmer for sensitivity adjustment, ensuring optimal performance in various applications. The NPN L/D selectable output allows for versatile integration, while the robust nickel-plated brass housing and IP67 protection degree provide durability in harsh environments.
Equipped with a yellow LED status indicator, these sensors offer complete protection against electrical damages, including short-circuit and reverse polarity protection. The M18 x 1 dimensions and M12 metal connector ensure easy installation and secure connections. With a switching frequency of 250Hz and a response time of just 2ms, the SSD/0N-1E Sensors deliver fast and accurate detection.
Designed to withstand temperatures ranging from -25°C to +70°C, these sensors are suitable for a wide range of industrial applications. The inclusion of nuts and a screwdriver as supplied accessories facilitates hassle-free setup. Additionally, the sensors are CE and cULus listed, ensuring compliance with international safety standards. Whether you require axial or right-angle optic positioning, the Datasensing SSD/0N-1E Sensors provide reliable performance with LO/DO selectable output and optional ATEX models for specialized needs.
- Nominal sensing distance:
- 14m
- Thermal drift of Sr:
- ?10% Sr
- Repeat Accuracy:
- 5%
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Receiver
- Emitter/Receiver:
- Receiver
- Optic position:
- Axial
- Output type:
- NPN L/D Selectable
- Output Function:
- L/D Selectable
- Switching frequency:
- 250Hz
- Response time:
- 2ms
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Leakage current:
- ?10?A
- Output voltage drop:
- ?2,5V@Iload=100mA
- Max ripple content:
- ?10%
- LED indicators:
- Yellow (status output)
- Time delay before availability:
- ?200ms
- Short-circuit protection:
- Yes
- Reverse Polarity Protection:
- Yes
- Emission:
- LED Infrared (880nm)
- Interference to external light:
- 5000lux (incandescent lamp), 10000lux (sunlight)
- Impulsive Overvoltage Protection:
- Yes
- Weight:
- 100g
- Housing Material:
- Nickel plated brass / PC plug
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Tightening torque:
- 25Nm
- Operating temperature:
- - 25°C + 70° C (Without freeze)
- Diameter/Dimension:
- M18
- Approvals:
- CE cULus
- EMC compatibility:
- EN 60947-5-2
- Shocks and vibrations:
- Vibration IEC 60068-2-6 / Shock IEC 60068-2-27
- Degree of protection:
- IP67
- Supplied Accessories:
- nuts M18 x 1, screwdriver
- Operating Temperature:
- - 25°C + 70°C (Without freeze)
- Mechanical Protection:
- IP67
