Datasensing STC 80 Sensors
Datasensing
$30.17
The Datasensing STC 80 Sensors are designed for precision and reliability, featuring a compact cubic 50x50 mm design with a robust ABS/PMMA housing. These photoelectric sensors utilize a red laser emission with trimmer adjustment for proximity detection, offering a nominal sensing distance of 900mm. The sensors support both NPN and PNP output configurations with NO+NC functions, ensuring versatile application compatibility.
With a response time of just 0.2 seconds and an operating voltage range of 10 to 30 VDC, these sensors are efficient and quick to respond. They are equipped with short-circuit and reverse polarity protection, as well as impulsive overvoltage protection, ensuring durability and safety in various environments. The sensors are capable of handling a no-load supply current of ? 30mA and a load current of ?100mA, with an output voltage drop of ?2V at a load of 100mA.
The STC 80 Sensors are designed to withstand external light interference according to EN 60947-5-2: 2020 standards and offer excellent insulation resistance of over 20 M? at 500 Vdc. They are built to endure shocks and vibrations with a mechanical protection rating of IP67, making them suitable for demanding industrial applications. The sensors are easy to connect with an M12 plug and are approved by CE and cULus standards, ensuring high quality and compliance.
- Nominal sensing distance:
- 900mm
- Sensitivity adjustment:
- Trimmer
- Function Principle:
- Diffuse beam
- Description:
- Compact square case
- Optic position:
- axial
- Functions:
- Diffuse beam
- Output type:
- PNP NO+NC
- Output Function:
- NO+NC
- Response time:
- 0,2
- Operating Voltage:
- 10 30VDC
- No-Load supply current:
- ? 30mA
- Load current:
- ?100mA
- Output voltage drop:
- ?2V@Iload=100mA
- Short-circuit protection:
- YES
- Reverse Polarity Protection:
- Yes
- Emission:
- LASER Red
- Interference to external light:
- according to EN 60947-5-2 : 2020
- Impulsive Overvoltage Protection:
- Yes
- Insulation resistance:
- >20 M? 500 Vdc, between electronics and housing
- Contact resistance:
- 500 Vac 1 min., between electronics and housing
- Housing Material:
- ABS / PMMA
- Connections:
- M12 plug
- Active Head Material:
- PMMA
- Storage temperature:
- - 25°C +70°C
- Diameter/Dimension:
- Cubic
- Approvals:
- CE cULus
- Shocks and vibrations:
- 0.5 mm amplitude, 10 55 Hz frequency, for every axis (EN60068-2-6)
- Mechanical Protection:
- IP67
