Datasensing TFM1/8X-0V Sensors

The Datasensing TFM1/8X-0V Sensors are advanced time of flight miniaturized sensors designed for precision and reliability. With a nominal sensing distance of 180mm and a wide angle emission of 25°, these sensors offer exceptional performance in various applications. The sensors feature a programmable switching frequency ranging from 10 Hz to 80 Hz, ensuring adaptability to different operational needs. Equipped with two digital outputs, the sensors provide selectable output options of PNP or Push-Pull, with a resolution of 1mm and a hysteresis of ±12mm. Built to withstand challenging environments, the TFM1/8X-0V Sensors boast an IP67 protection degree, offering complete protection against electrical damages and ensuring durability. The sensors are filled with resin for enhanced robustness and feature short-circuit and reverse polarity protection for added safety. The infrared laser emission (class 1) ensures precise detection, while the LED indicators provide clear status updates with green for run, red for out of range, and yellow for status. Designed with user convenience in mind, the sensors include a trimmer for sensitivity adjustment and a time delay before availability of ?200ms. The compact dimensions of 13 x 2 x 31.2mm and a cubic design make them easy to integrate into various systems. Operating efficiently within a voltage range of 19.2 to 28.8VDC, the sensors maintain a low no-load supply current of ?40mA and a load current of ?50mA. The housing material of PA66 + ABS and an active head made of glass ensure durability, while the operating temperature range of -10°C to +50°C allows for versatile use. With CE approvals and EMC compatibility, the Datasensing TFM1/8X-0V Sensors are a reliable choice for precise sensing needs.
